NPB palletizer for ends
The automatic palletizer features a modular design, which makes it easy to ship, install and operate. It can be made for one to four pallet places.
In feed
The bags can be fed into the machine in various ways, depending on the layout.
Palletizing
The bags can be palletised in one or two stacks after each other. The pallet is built up automatically with integrated sling-wrap-paper.
The pattern for the bags and the sling-wrap-paper can easily be programmed from the operator’s panel. The pallet change can be made manually or fully automated.
Technical specification
-
Product data Capacity, standard machine 12 bags per minute Dimensions, product Ø50-200 mm (200-709) Bag length up to 1200 mm (47 ¼ in) Material Steel or aluminium Pallets Various Sling-wrap-paper Two parallel rolls Technical data Height 5000 mm (16,4 ft) Length 1800 mm (6 ft) Width 5000-7000 mm (16,4-23 ft) Power 3x400-480 VAC/10 A, 50-60Hz Air pressure 0.6 MPa (87psi) Control-system Allen-Bradley/Siemens -
Options Conveyor for empty and full pallets. Automatic pallet-change. Left or right-handed layout. Dispenser for empty pallets. QC-function. Fact sheet PDF NPB Palletizer
